SeaChanger™ HMI

The 24,000 lumen SeaChanger™ HMI is the perfect choice for applications requiring bright light, high color temperature, great color rendering and long working distances. The SeaChanger™ HMI is ideal for live events and theatrical installations where there is a need to cut through ambient stage and outside lighting. In addition, the Seachanger™ HMI provides an excellent light source for TV and film production where high CRI and adjustable color temperature is required. The long throw capability and fast color snaps of the Speedster dichroic color engine makes the SeaChanger™ HMI great for indoor and outdoor themed attractions (when installed in an approved outdoor enclosure) as well as general architectural illumination.

Specifications
Speed: Color changes in less than 0.5 seconds with Speedster color engine
White Light Output: 24,000 lumens total system output, 95 CRI
Control:

DMX512 5-pin male and famale XLR
RDM device per ANSI E1.20-2006
Front panel membrane keypad with LED numeric display

Filter/Channel Features:

Ch. 1 - Cyan, 0-100% saturation
Ch. 2 - Magenta, 0-100% saturation
Ch. 3 - Yellow, 0-100% saturation
Ch. 4 - Micropatterned Dimmer 0-100%
Ch. 5 - SeaChanger HMI Lamp Electronic Dimming
Ch. 6 - SeaChanger HMI Lamp Strike / Douse

Electrical:

SeaChanger Color Engine
110/240 VAC, 50/60 Hz, (auto-sensing), non-dimmed circuit,
.3 Amps @ 110 VAC, .15 Amps @ 240 VAC
Speedster color engine includes 22 dB cooling fan

SeaChanger HMI Lamp:

Flicker Free Electrical Ballast provides for DMX control and manual control
90/265 VAC 50/60 Hz (auto sensing), non-dimmed circuit
7 amps @ 110v, 4 amps @ 240v

Lamp Type:

Philips MSR 575w HR (theatrical)
Philips MSD 575 1CT (architectural)

Lamp Life:

1,000 hours estimated (theatrical)
3,000 hours estimated (architectural)

Color Temperature: 6000°K
Maintenance: Easy-out color engine removal for cleaning; safety cable ring; 3' safety cable included

Does not include ETC Source Four® components or yoke

Download PDF

Attractions

When you need throw distance and every lumen counts, the SeaChanger™ HMI is the right choice. The powerful 24,000 lumen color changer has the output and color changing ability to cut through the thickest theatrical fog and daylight. One SeaChanger™ HMI can equal the light output of multiple fixtures, saving power, hardware, and maintenance costs. The 0.5 second color speed is perfect for live events, shows and themed attractions.
